Benelli TNT25 User Manual

80
EN
MAIN CONTROLS
LEFT DIAL
1) High beam / low beam light
control
Set this switch to “ ” for high beam
lights and to “ ” for low beam lights.
2) Left/right position indicator
switch
Press this switch to enable the left and
right and rear indicators.
Press the centre to disengage them.
3) Sound warning switch
Press this switch to enable the sound
alarm.
4) Passing button
Press this button (daytime) to enable
flashing lights
RIGHT DIAL
1) Electric ignition button
Press this button to start the engine with
the starter device.
1
2
3
1
MAIN CONTROLS
WARNING:
2
3
4
Senza titolo-2 17 21/12/2015 15:49:50
2) Emergency light button
With the ignition key set to “ ” use
this switch to switch on the emergency
lights (simultaneous flashing of all of the
direction indicators).
The emergency lights are used in case
of emergency, to advise the other road
users that your vehicle is about to stop in
dangerous traffic areas.
Do not use the emergency lights when
the engine is off; this is to stop the
battery from becoming flat.
3) Engine off button
Set this switch to “ ” before switching
on the engine. Set this switch to “ ” to
switch off the engine in case of emerge-
cy, such as, for example, when the
motorbike tilts over or the accelerator
cable is blocked.
Benelli TNT25 Owner's Manual
http://www.motorcycle.in.th

Benelli TNT25 Specifications

General

Displacement	249.2 cc
Bore x Stroke	72 mm x 61.2 mm
Compression Ratio	11.2:1
Starting System	Electric
Transmission	6-speed
Clutch	Wet multi-plate
Front Brake	280 mm Disc
Front Tire	110/70 - 17
Rear Tire	150/60 - 17
Length x Width x Height	2080 mm x 810 mm x 1125 mm
Seat Height	780 mm
Wheelbase	1400 mm
Kerb Weight	159 kg
Engine Type	Single Cylinder, 4 Stroke, Liquid Cooled
Maximum Torque	21.6 Nm @ 8000 rpm
Fuel System	Electronic fuel injection
Ignition	ECU
Frame Type	Steel trestle
Front Suspension	Upside Down Telescopic Forks
Rear Suspension	Hydraulic Monoshock
ABS	No
