105
EN
TECHNICAL SPECIFICATIONS
MODEL BN 251
Cubic capacity: 249 cc
Cylinders: 1
Cooling system: fluid
Stroke ratio: ø 72x61.2 mm
Compression ratio: 11.2:1
Max. power rpm:
18.5 Kw/9000 rpm
Max. torque: 21.5 Nm/7500 rpm
Battery: 12V 6Ah
Ignition: Electric
Power: Electronic injection with one throttle valve ø 37 mm
Clutch: Oil bath multi-disc
Gears: Pedal: 6
Height: 1125 mm
Wheel base: 1400 mm
Length: 2080 mm
Width: 810 mm
Net weight: 143 Kg
TECHNICAL SPECIFICATIONS
Senza titolo-2 42 21/12/2015 15:50:03
Benelli TNT25 Owner's Manual
http://www.motorcycle.in.th

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Benelli TNT25 and is the answer not in the manual?

Benelli TNT25 Specifications

General IconGeneral
Displacement249.2 cc
Bore x Stroke72 mm x 61.2 mm
Compression Ratio11.2:1
Starting SystemElectric
Transmission6-speed
ClutchWet multi-plate
Front Brake280 mm Disc
Front Tire110/70 - 17
Rear Tire150/60 - 17
Length x Width x Height2080 mm x 810 mm x 1125 mm
Seat Height780 mm
Wheelbase1400 mm
Kerb Weight159 kg
Engine TypeSingle Cylinder, 4 Stroke, Liquid Cooled
Maximum Torque21.6 Nm @ 8000 rpm
Fuel SystemElectronic fuel injection
IgnitionECU
Frame TypeSteel trestle
Front SuspensionUpside Down Telescopic Forks
Rear SuspensionHydraulic Monoshock
ABSNo
