Benelli TNT25 User Manual

83
EN
MAIN CONTROLS
IMPORTANT:
KEY
The bike is supplied with 3 keys for:
- opening the fuel cap
- steering lock
- ignition
- opening the saddle
Always keep duplicate keys separately
from the bike
IMPORTANT:
IGNITION BLOCK
Never turn the ignition switch in position
while travelling, as this can cause acci-
dents.
It is advisable to apply an anti-freeze for
locks when the temperature reaches
around °0 to prevent the lock protection
hole from freezing.
IMPORTANT:
STEERING LOCK
Release
1) Insert the key in the steering lock.
2) Turn the key clockwise.
NOTE:
Senza titolo-2 20 21/12/2015 15:49:52
The key block, in the centre of the
vehicle, has two main functions:
“ ” The engine and lights can
function. The key cannot be removed.
“ ” The engine and lights cannot
function. The key can be removed.
Lock the steering and remove the key
while parked to prevent any unauthori-
sed use of the vehicle.
Locking
1) Turn the handlebar completely to the
left.
2) Insert the key in the ignition.
3) Turn the key anticlockwise, in the “ ”
position to lock the steering.
To make it easier to engage the steering
lock, move the handlebar slightly while
turning the key.
4) Remove the key.
After locking, try turning the handlebar
slightly to make sure that the steering is
actually locked.
Benelli TNT25 Owner's Manual
http://www.motorcycle.in.th

Benelli TNT25 Specifications

General

Displacement	249.2 cc
Bore x Stroke	72 mm x 61.2 mm
Compression Ratio	11.2:1
Starting System	Electric
Transmission	6-speed
Clutch	Wet multi-plate
Front Brake	280 mm Disc
Front Tire	110/70 - 17
Rear Tire	150/60 - 17
Length x Width x Height	2080 mm x 810 mm x 1125 mm
Seat Height	780 mm
Wheelbase	1400 mm
Kerb Weight	159 kg
Engine Type	Single Cylinder, 4 Stroke, Liquid Cooled
Maximum Torque	21.6 Nm @ 8000 rpm
Fuel System	Electronic fuel injection
Ignition	ECU
Frame Type	Steel trestle
Front Suspension	Upside Down Telescopic Forks
Rear Suspension	Hydraulic Monoshock
ABS	No
