below or equal to about 5 km/h.
• The ABS does not work in case of low
battery.
NOTICE
Be careful not to damage the wheel sensor
or wheel sensor rotor; otherwise, improper
performance of the ABS will result.
1. Front wheel sensor
2. Front wheel sensor rotor
1. Rear wheel sensor
2. Rear wheel sensor rotor
Fuel tank cap
To open the fuel tank cap
Open the fuel tank cap lock cover, insert the
key into the lock, and then turn it 1/4 turn
clockwise. The lock will be released and the
fuel tank cap can be opened.
To close the fuel tank cap
1. Push the fuel tank cap into position with the
key inserted in the lock.
2. Turn the key counterclockwise to the ori-
ginal position, remove it, and then close the
lock cover.
1
1
2
1
1
1
2
1
