2 - 2
Descrizione
IT
2
Vista da destra
1. Serbatoio del liquido freno posteriore
(6-21)
2. Tappo serbatoio carburante (3-11)
3. Faro (6-31)
4. Tappo radiatore (6-14)
5. Serbatoio liquido refrigerante (6-13)
6. Oblò ispezione livello olio motore
(6-10)
7. Tappo bocchettone riempimento olio
motore (6-10)
8. Pedale freno (3-9)
1
2
3
4
5
6
7
8
