FRONT/ REAR BRAKE ADJUSTMENT
1.
•
Check:
Brake lever free play
1
Out of specification → Adjust.
Free play (brake lever):
3
2.
•
Adjust:
5 mm (at brake lever end)
Brake lever free play
*****************************************************
A
•
djustment steps:
•
Loosen the locknut
2
.
Turn the adjuster
3
in or out until the speci-
fied free play is obtained.
Turning in → Free play is decreased.
Turning out → Free play is increased.
Tighten the locknut.
CAUTION:
Make sure that there is no brake drag after
adjusting the front brake lever free play.
A soft or spongy feeling in the brake lever
can indicate the presence of air in the brake
system. This air must be removed by bleed-
ing the brake system before the motorcycle
is operated. Air in the brake system will con-
siderably reduce braking performance and
could result in loss of control and possibly
an accident. Inspect and bleed the brake
system if necessary.
****************************************************
