7.5 Front fork
7.5.1 Disassembly
Remove the front wheel.
Remove the front shield, front inner fender
and front fender.
Remove the brake hose and the odometer
cable.
Loosen the gland nut and the lock washer.
Remove the upper and the lower bearing
cups. Remove the front forks.
Tools:
Fixing bolt spanner for the steering
handle. Fixing nut spanner.
Special disassembly tool for bearing cups.
* Note:
•The opening of the body guard
shall be cleaned with cloth.
7.5.3 Installation
Tools:
Fixing nut spanner.
Ensure the front fork is not loose by left and right
movement. Steps:
Install the steering handle.
Install the front absorber.
Install the front wheel.
