Valve Inspection
Measure the free length of valve spring.
Usage limit：spring：inner 29.92mm
①
outer 34.4mm
①：vernier calliper
Measure the OD of valve lever.
Usage limit：4.43mm
Inspect the valve guide, please use a
reamer before inspection.
①
Clear out the carbon deposits in the valve guide
pipe.
Notice: please turn the reamer clockwise. Do not turn
the reamer counter-clockwise.
①：valve reamer
