Benelli ZAFFERAN 250 - Front Wheel

70
Front Wheel
A
Front wheel spec:
tire120/70-14
B
Installation torque of
nut 14: 75-88N·m
C
Rim run-out limit:
Vertical: 2.0mm
Horizontal: 2.0mm
D
Front wheel camber
limit：0.2mm
E
Front wheel
certificate number:
1.) Front wheel axle 2.) Brake rotor bolt 3.) Brake rotor 4.) Left front wheel spacer 5.) Oil seal 6.)
Bearing 7.) Valve stem cap 8.) Valve stem 9.) Tire 120/70-14 10.) Front wheel 11.) Bearing spacer
sleeve 12.) Speedometer drive unit 13.) Washer 14.) Nut
