Base-2 Security Panel
ENGLISH
PROGRAMMING
Base-2 can be programmed via the on-board DIP Switch strip [12]. This section
describes the programming procedure.
Alarm Time
Using switches 1 and 2 program the Alarm Time, as per the following table. The
OFF time is already programmed at 5 seconds (at Factory).
Alarm Cycles
Using DIP Switch no. 3, program “Persistent Alarms” to generate either a single
Alarm cycle (at Factory), or Repetitive Alarm Cycles (i.e. until Standby status
is restored), as follows.
Zone 1 Delayed
Using DIP Switch no. 8 program the Zone 1 as either “Delayed” or “Instant” , as
follows.
Entry and Exit Times
If Zone 1 is programmed as “Delayed”, using DIP switches 5, 6 and 7 set the
Entry and Exit Times, as follows.
ZON E 1 OPER ATIN G M OD E 1 DIP SWITCH 8
Delayed (at Factory) OFF
Instant ON
ALARM TIME
DIP SWITCH
1 2
1 minute (at Factory) OFF OFF
3 minutes OFF ON
5 minutes ON OFF
10 minutes ON ON
RELAY 1 MODE FOR
PERSISTENT ALARM ON ZONE
DIP SWITCH 3
Single cycle (at Factory) OFF
Repetitive Cycles ON
Programming the Panel
