Base-2 Security Panel
ENGLISH
ZONE BALANCE DIP SWITCH 4
Normally Closed (at Factory) OFF
Balanced 10K ON
ENTRY TIME EXIT TIME
DIP SWITCH
5 6 7
30 s (at Factory) 30 s (at Factory) OFF OFF OFF
5 s 5 s OFF OFF ON
30 s 10 s OFF ON OFF
45 s 45 s OFF ON ON
60 s 45 s ON OFF OFF
60 s 60 s ON OFF ON
90 s 60 s ON ON OFF
90 s 90 s ON ON ON
BUZZER DIP SWITCH 10
Enable (at Factory) OFF
Disable ON
INDOOR SIREN OUTPUT DIP SWITCH 9
UnBypassed and Bypassed Mode
(at Factory)
OFF
Bypassed Mode only ON
Zone Balance
Using DIP switch no. 4 program the operating mode of the Zone Inputs, as
follows.
Indoor Siren Output
Using DIP Switch no. 9 program the Indoor Siren Output to signal Alarm status
in Bypassed and UnBypassed mode, or UnBypassed mode only, as follows.
Enable Buzzer on Proximity Readers
Using DIP Switch no. 10 enable or disable all the Proximity Readers Buzzers, as
follows.
