Bentone B 30/B 40 J/K
3.3 Examples of basic setting B40
Burner output 200 kW
Estimated nozzle output 200 kW/11,86 kWh/kg*= 16,9 kg/h
Nozzle selection in accordance with the table. (See technical data) Nozzle
selection is based on the selected pump pressure and the desired effect.
According to the nozzle table, this provides the following nozzle.
Selected pump
pressure
10 bar
Nozzle 4,50 gph
Power in 16,75 kg/h => 16,75 kg/h x 11,86 kWh/kg = 198 kW
Effects and nozzle selection from example
Nozzle assembly 1
Damper 6
Basic settings should only be seen as setting values to get burner to start
and establish a flame. Once the burner has started and established a flame,
it will be necessary to adjust the settings so that they are adapted to the
installation in question and the fuel used at the time.
Basic settings
The setting value for 200 kW in accordance with basic setting tables. For the
correct procedure when implementing settings, see 3.6 Nozzle assembly
control, brake plate B40 and 3.7 Air setting B40 (See technical data )
