5 Functional Processes Volume 7
5.4 Radiation Interference Detection
 Go to the function block Resource.
 In the record
FL_INTERFERENCE_DETECTION enable or disable
the radiation interference detection via the parameter
FL_DETECTION_MODE.
 Send the entry to the Uni-Probe.
 In the parameter FL_DETECTION_THRESHOLD, enter the
threshold value for the start of the suppression of sensor values.
 In the parameter
FL_DETECTION_HOLD_TIME, enter the dura-
tion of the suppression, i.e. the time the measured pulse rate is
not taken into account.
 Send the entries to the Uni-Probe.
This completes the setting.
5.5 Input Configuration
Only one digital input is available.
 Go to the function block
Resource.
 Via the parameter
FL_DIGITAL_INPUT_ENTRY, select the de-
sired function: Hold or Reset Mass Integrator input.
 Send the entries to the Uni-Probe.
 Enable or disable the input via the parameter
FL_DIGITAL_INPUT_FUNCTION.
 Send the entry to the Uni-Probe.
This completes the setting.
The status of the digital inputs can be viewed in the record
FL_DIGITAL_INPUT_TEST_VALUES in the sub-parameter
FL_DI1_STATE.
Parameters used
FL_INTERFERENCE_DETECTION
FL_DETECTION_MODE
FL_DETECTION_THRESHOLD
FL_DETECTION_HOLD_TIME
Parameters used
FL_DIGITAL_INPUT_ENTRY
FL_DIGITAL_INPUT_FUNCTION
