Beta X-Trainer 300 2T User Manual

1
GENERAL INFORMATION
15
GB
LEGEND ELECTRICAL DIAGRAM
1) RIGHT-HAND FRONT TURN INDICATOR 12V 6W
2) FRONT BRAKE LIGHT BUTTON
3) START BUTTON
4) WHEEL REVOLUTION SENSOR
5) TURN INDICATORS WARNING LIGHT
6) OIL RESERVE WARNING LIGHT
7) DASHBOARD
8) HEADLIGHT TELL TALE LAMP
9) MIXER DIAGNOSIS WARNING LIGHT
10) ENGINE STOP BUTTON
11) HORN BUTTON
12) HEADLIGHT SELECTOR
13) TURN SIGNAL LAMPS SWITCH
14) LEFT-HAND CONTROL GROUP
15) LEFT-HAND FRONT TURN INDICATOR 12V 6W
16) REGULATOR
17) ELECTRIC FAN
18) THERMOSWITCH
19) UNIT TURN SIGNAL LAMPS
20) LEFT-HAND REAR TURN INDICATOR (12V 6W BULB)
21) TAIL LIGHT WITH LED
22) NUMBER-PLATE LIGHT
23) RIGHT-HAND REAR TURN INDICATOR (12V 6W BULB)
24) REAR STOP BUTTON
25) FRAME EARTH
26) BATTERY 12V 4AH
27) BATTERY NEGATIVE TERMINAL
28) BATTERY POSITIVE TERMINAL
29) STARTER RELAY
30) STARTER MOTOR
31) 10A FUSE
32) CHARGER DIODES GROUP
33) CONDENSATOR 4700 μF
34) MIXER OIL PUMP
35) GENERATOR
36) ELECTRONIC CONTROL UNIT
37) TPS
38) HT COIL
39) SPARK PLUG
40) FRAME EARTH
41) OIL RESERVE SENSOR
42) PARKING LIGHT 12V 5W
43) HEADLIGHT (12V-35/35W BULB)
44) 12V HORN
