OPERATION
20
GB
LH SWITCH
The dip and service switch is located on
the left side of the handlebar and is com-
posed as follows:
1 - Horn button;
2 - Dip switch:
l only parking lights;
parking lights and high beam;
parking lights and low beam;
3 - Shut-down : press the button until
the engine stops;
4 - Turn signal light switch: shifting lever
left or right activates the left or right
indicators. When released, the lever
returns to the central position. Press it
to turn the indicators off.
1
2
3
4
STARTER BUTTON
Starter button is located on the right-hand
side of the handlebars and operate the
electric engine starter. Push the button until
the engine starts.
Do not press the button while the engine
is running.
FRONT BRAKE LEVER AND GAS
CONTROL
The front brake lever 1 and the gas throt-
tle 2 are located on the right side of the
handlebar.
1
2
