4
CHECKS AND MAINTENANCE
73
GB
TIGHTENING TORQUE OVERVIEW
Here below is an overview of the tightening torque of all pieces subject to adjust-
ment or maintenance:
Forecarriage
Tighteningtorque[Nm] Threadlock
Wheel pin 50
Fork foots - wheel pin 20
Cavallotto parastelo sinistro 1,5
Steering head base - fork legs 12*
Steering head - fork legs 17*
Stem pin on steering head 20
Lower handlebar u-bolt - steering head 40 M
Upper handlebar u-bolt -
lower handlebar u-bolt
25
Rear axle
Tighteningtorque[Nm] Threadlock
Wheel pin 130
Rear shock absorber - frame 70
Rear shock absorber - rocker arm 70
Connecting rod - frame 90
Connecting rod - rocker arm 90
Rocker arm - swinging arm 90
Engine
Tighteningtorque[Nm] Threadlock
Gearbox oil drain plug 15
Engine - Frame
Tighteningtorque[Nm] Note
Pins motor - frame 45
Brackets to attach the head - frame (front fixing) 35 M
Brackets to attach the head - frame (rear fixing) 35
M
Brackets to attach the head - motor 35
M Medium strength threadlock
* WARNING:
Tightening of the screws should be carried out by adjusting the torque
wrench to the stability torque with repeated tightening until stability torque
has been achieved.
