Beta X-Trainer 300 2T - Carburetor Settings According to the Working Conditions

3
ADJUSTMENTS
36
GB
To properly adjust the idle speed, follow these steps:
•Tighten the air adjustment screw no. 2 fully and then loosen it up to the value described
in the carburetor setting table (page 12)
•Warmtheengineforapprox.5minutes,untiltheoperationaltemperatureisattained.
•Slowlyturntheairadjustmentscrew2 clockwise, until idling starts diminishing.
•Marktheposition,thenslowlyturntheairadjustmentscrewno.2 counterclockwise, until
idling decreases again.
•Adjustthescrewbetweenthesetwopositions,atthehighestidlingpoint..
If a remarkable increase in the rpm occurred during the adjustment above, idling is to be
reduced and taken back to the normal level, and then execute the above procedure.
If no satisfactory results are obtained after the procedure, this may be due to an incorrect
slow-running jet.
If the air adjustment screw has been thoroughly tightened, but the rpm have not varied, a
lower size slow-running jet is to be used.
Execute the adjustment procedure again after replacing the jet.
NOTE:
The correct idling should be between 1500 and 1600 rpm.
CARBURETOR SETTINGS ACCORDING TO THE WORKING CONDITIONS
See the following tables to adjust the carburetor settings according to ambient tem-
perature and altitude.
Legend:
SLM Above sea level
AVA Air screw opening (from all closed)
Gm Slow jet
SPL Needle
POS Needle position (from top)
GM Main jet
VLV Valve
Standard settings
