4
CHECKS AND MAINTENANCE
50
GB
CARBURETTOR
DRAINING THE CARBURETTOR
FLOAT CHAMBER
If the carburettor tank needs to be emptied,
proceed as described.
Remove the chain protection 1, close the
tank tap and put a cloth under the carbu-
rettor, so that you can collect the running
out fuel.
Open the drain screw 2 to drain the fuel.
Close the drain screw.
Apply the chain protection and tighten the
screws at 10Nm.
WARNING:
Follow action on a cold engine.
WARNING:
Fire hazard. Fuel is highly flam-
mable.
Always stop the engine when
refuelling and keep open
flames and lighted cigarettes
away.
Refuel in an open well ventilated area.
Immediately clean up any spilled
fuel.
2
1
