4
CHECKS AND MAINTENANCE
60
GB
CHECK AND ADJUSTING OF
STEERING PLAY
Periodically check the play in the steering
sleeve by moving the fork back and forth
as shown in the figure. Whenever you feel
play, adjust as described below:
- Loosen the screws 1
- Loosen the screw 2
- Reduce the play by turning nut 3
Tighten the screws to the prescribed torque
values.
2
3
17Nm
11
20Nm
