3
ADJUSTMENTS
35
GB
ADJUSTMENT OF GAS
CLEARANCE
The throttle control cable should always
have a 3-5 mm play. In addition, the idle
speed should not change when the han-
dlebars are fully rotated to the left or right.
Push back protective cap 1. Loosen coun-
ternut 2 and turn adjusting screw 3.
Tighten the counternut and check that the
throttle twist grip turns smoothly.
2
3
1
ADJUSTING THE IDLE SPEED
Idling adjustment greatly affects the ap-
propriate start-up and the accelerator
response.
Idling is adjusted through adjustment screw
1 and air adjustment screw 2. Adjustment
screw 1 adjusts the basis position of the
gas valve. Turn the screw clockwise to
increase the rotation conditions and coun-
terclockwise to diminish it. The air adjust-
ment screw 2 adjusts the quantity of which
is mixed to the fuel for idling. If the screw is
turned counterclockwise, the quantity of air
increases (thin mix), if turned clockwise, the
quantity of air diminishes (fat mix).
1
2
