Table 4-2 Programmable Parameters - Continued
Parameter Factory Setting Description
70A 90A
INHIBIT MENU
Type 2 2
The flexible speed input at J1 Pin 6 can be used to limit or to
inhibit speed under certain conditions. For example, a switch
could be installed under the seat so that if the operator drives
the scooter while they are standing the max speed will be lim-
ited.
The Inhibit Type parameter is used to select how the inhibit
function will be implemented. Depending on how the inhibit
switch is wired into the system, set this parameter to:
0 = B- active
1 = B+ active
2 = Open circuit active
3 = B- inactive
4 = B+ inactive
5 = Open circuit inactive.
Speed 0% 0%
This parameter limits the maximum speed allowed during
speed inhibit mode. A setting of 0 prevents drive during
inhibit mode.
BRAKE MENU
Delay 0.3 sec. 0.3 sec
Sets the length of delay between when zero speed is com-
manded and the electromagnetic brake is engaged.
Fault Check OFF ON Enables/disables the fault detection on the EM brake.
Hold Voltage 18V 18V
A high initial voltage is applied to the brake coil when the brake
is first released. After approximately 1 second, this peak volt-
age drops to the programmed Hold Voltage. The parameter
should be set high enough to hold the brake released under
all the shock and vibration conditions the vehicle will be sub-
jected to.
Brake Light OFF OFF
When set to On, the horn output (J1 Pin 3) will act as a brake
light driver. The brake light must be driven by a relay. The
brake light will be turned on when the throttle is returned to
neutral and will remain on for about 2 seconds after the EM
brake is engaged.
HORN MENU
Fault Beep OFF N/A
When programmed On, the horn will be used to provide audi-
ble fault codes whenever faults are present. These are the
same fault codes that are flashed by the status LED. If a fault
should occur while the vehicle is driving in reverse with the
reverse beep active, the fault signal will take precedence. If
this audible fault alarm is not wanted, set Fault Beep to Off.
Reverse Beep ON ON
When programmed On, the horn will sound whenever the vehi-
cle is being driven in reverse. On vehicles with reverse
switches, the horn will sound when the reverse switch is acti-
vated.
Beep Constant OFF OFF
Sets the reverse beep to be a constant tone (when pro-
grammed On) or a 1Hz pulse (when programmed Off).
