BL-E30-0515 - 03-01-2018 9-1
SECTION 9
HYDRAULIC SYSTEM SERVICING
9-1. LINES AND FITTINGS
WARNING: When forks are raised, pressure exists in
the hydraulic system lines and fittings. To
ensure release of pressure, forks must
be fully lowered before performing any
maintenance on the hydraulic system.
NOTE: Leaking hydraulic fittings may be remedied by
simply tightening fittings. If this does not rem-
edy the leak, the fittings or line must be
replaced.
1. Lower forks fully.
2. Turn off the key switch (20, Figure 12-18) and
emergency disconnect (17).
3. Remove the upper compartment cover (5, Figure
9-1) as described in paragraph 5-2.
Figure 9-1 Compartment Cover
