BIGTREETECH KRAKEN V1.0 User Manual

BIGTREETECH Kraken V1.0 User Manual
6
 Reserved SPI interface for connecting an accelerometer for Klipper
resonance compensation.
 External DC12V powers the MOSFET control power for TMC2160, reducing
driver output impedance and chip heat generation.
Specifications
MCU
ARM Cortex-M7 STM32H723ZGT6 550MHz
Driver Input Voltage
HV (24-60V)
Motherboard Input
Voltage
DCIN = DC12V or DC24V
Heated Bed Input
Voltage
BED IN = DC12V or DC24V
Logic Voltage
DC3.3V
Heating Interface
Heating Interface: Heated Bed (HB), Heater Cartridge
(HE0, HE1, HE2, HE3)
Max Heated Bed Output
Current
10A,
peak 11A
Max Heater Cartridge
Output Current
6A, peak 6.5A
Fan Interfaces
6x 2-pin PWM Fans (FAN0, FAN1, FAN2, FAN3,
FAN4, FAN5), 2x 4
-pin PWM Fans (FAN6, FAN7), 5x
Always
-On Fan, PWM Fans Voltage (5V, 12V, 24V)
Selectable
Max Fan Output Current
1A, peak 1.5A
Total Current for Heater
Cartridge + Fans
Less than 14A
Motherboard Max 5V
Output Current
5A (peak 6A)
Motherboard Max 12V
Output Current
5A (peak 6A)
Expansion Interfaces
Probe (Servos, Probe), Servo, Filament Sensor, PS-
ON, I²C, RGBx2, SPI, SBC (UART), EXP1+EXP2,
