BIGTREETECH MANTA M5P V1.0 User Manual

Shenzhen Big Tree Technology Co., Ltd.
BIGTREETECH
6 / 35
Specifications
Dimensions
137.5mm x 95mm,
for details please refer to
BIGTREETECH MANTA
M5P V1.0-SIZE-top.pdf
Mounting Size
Please refer to
BIGTREETECH MANTA M5P V1.0-
SIZE-top.pdf
MCU
ARM Cortex-M0+ STM32G0B1RET6 64MHz
Driver Input Voltage
VIN (DC12V-24V), HV (DC24V-56V) Selectable
Motherboard Input
Voltage
VIN=DC12V or DC24V
Logic Voltage
DC 3.3V
Heater Connection
Heated Bed (HB), Heater Cartridge (HE0, HE1)
HB Port Max Current
10A Continuous, 11A Instantaneous
Heater Cartridge Max
Current
5.5A Continuous, 6A Instantaneous
Fan Port
3 x 2 pins CNC (FAN0, FAN1, Pi-FAN) (5/12/24V
Selectable Voltage), 1 x Always On (FAN)
Fan Port Max Current
1A Continuous, 1.1A Instantaneous
Overall Current of Fan
Ports)
＜
2.5A
Expansion Port
CAN, Probe, RGBx2, SPI, EXP1+EXP2, MIN1-MIN4,
40Pin-GPIO
Motor Driver
Support TMC5160, TMC2209, TMC2225, TMC2226,
TMC2208, TMC2130, ST820, LV8729, DRV8825,
A4988...
Driver Mode
SPI, UART, STEP/DIR
