3.5 Analogue output connection (D70B version only)
The connector COM1 located on the rear of the terminal (point 2 Figure
3.2 on page 1-24) provides an analogue output in the forms 0-10 V and
0(4)-20 mA galvanically separated; the connection pinout is given in the
following table.
Pin n°
Signal
1
Output 0-10 V
6
Common
7
Output 0(4)-20 mA
CAUTION
Technical characteristics:
Resolution= 10000 points
Precision = 0.05 % FS
Minimum voltage output load = 100 kohm
Minimum current output load = 250 ohm
3.6 Programmable analogue output
This function is used for programming two voltage or current values and
a reference weight:
✔
output voltage or current for a weight equal to zero;
✔
output voltage or current for a weight equal to the reference weight;
✔
reference weight.
The programmed values are permanently memorized even when the
instrument is off.
For information about the parameters to set (AN.DATA), refer to par. 5.9
on page 1-46.
Refer to par. 9.4 on page 1-69 for the remote controls associated with
this function..
