5.9 Special Scale settings
Certain operating configurations can be varied to adapt the instrument to
the operator's particular requirements.
The following parameters can be edited by pressing :
YESISTCHG
(only valid for the
D70A version)
Charges the batteries in the terminal for the
first time
NO
Eliminates the programmed charge function
BATV
Displays the voltage measured at the input of
the terminal
(if the external battery
is selected)
Visualizza per 1 secondo il tempo di carica
CHAT
(Displays the charging
time for 1 second)
LIGHT HIGH
The display operates with the maximum light
intensity
LOW
The display operates at the minimum light
intensity
TIMER
The display operates at maximum intensity for
10 seconds if:
✔ any key is pressed;
✔ the weight indication is subjected to a
variation of at least 4 divisions.
D70
1-46
