01 0 1
bit0bit3 bit2 bit1
When a bit assumes the value "1" the corresponding signal is "true"; the
meaning of the signals is as follows:
<s1> bit 0 minimum weight signal
bit 1 tare locked signal
bit 2
tare preset (1)/self-weighed (0) entered signal
bit 3 centre zero signal
<s2> bit 0
LSB weighing extension signal (ME only)
bit 1 weight stable signal
bit 2 overload signal
bit 3
MSB weighing extension signal (ME only)
<s3> bit 0 tare entered signal
bit 1
tare locked cancelled signal (ME only)
bit 2 weight not valid
bit 3 printing in progress
<s4> bit 0 type approved instrument
bit 1
converter fault
bit 2
scale configuration parameter error
bit 3 not utilised
The following protocols are available: Cyclic (see par. 9.3.2 on page
1-68), ACK-NAK (see par. 9.3.1 on page 1-68), Remote commands (see
par. 9.4 on page 1-69).
There is a 300 ms ± 10% pause between the end of one string and the
beginning of the next.
D70
1-64
