Binary B-500-MTRX-230-4x4 - B-500-RX-230-IR IR Connections

B-500-MTRX-230-4x4 Installation Manual
Pg. 13
www.snapav.com Support: 866.838.5052
7.9. B-500-RX-230-IR IR Connections
TheB-500-RX-230-IRIRportsaredescribedbelow.Usethediagramforreference.
7.9.1. IR Receiver
AttachanIRreceivertothisporttocaptureIRcommandsintheroomforpass-throughforsources.Thisportwillalso
sendcommandsbacktothematrixswitcherforcontrolofsourceselectionineachzone.
7.9.2. IR Flasher
AttachanIRashertothisportforcontrollingadisplayorotherequipmentwithcommandssentfromacontrolsystem
asheroutput,intothematrixswitcherIRINPUTTOROOMportsandthentothisport.
1 2
IR Signal (Tip)
GND (Ring)
12V DC (Sleeve)
IR Signal Tip
GND (Ground) Ring
+12V DC Sleeve
IR Signal (Tip)
GND (Sleeve)
IR Signal Tip
GND (Ground) Ring
7.9.3. Yellow Tag IR Adapter
Theyellowtaggedadapter(illustratedbelow)includedwiththeB-500-RX-230-IRisusedwhenplugginga3.5mm
monominicableintotheIRReceiverportoftheB-500-RX-230-IR.ThisisusedtosendIRcommandstothematrix
switcherlocationfromotherdevices,insteadofanIRReceiverthatusesa3.5mmmonominiportforoutput.
IR Signal (Tip)
GND (Ring)
12V DC (Sleeve)
IR Signal (Tip)
GND (Sleeve)
To IR Control System
or
Connecting Block
To B-500-MTRX
