B-500-MTRX-230-4x4 Installation Manual
Pg. 20
© 2013 Binary
™
9. AdvancedSetupUsingtheCongurationUtility
10. Firmware Update
There are several setup options available that can only be modied using the matrix switcher Conguration Utility.
Theseitemsaredefaultedtothemostcommonsettingsthatshouldworkinmostinstallations.
TheCongurationUtilityandmanualareavailablefordownloadontheSupportTaboftheB-500-MTRX-230-4X4product
pageatwww.SnapAV.com.DownloadandruntheUtilitytogainaccesstothesesettingsbyconnectingtothematrixand
clicking“OtherSettings.”
BinarymayoccasionallyreleasenewrmwarefortheB-500-MTRX-230-4X4toaddressnewstandardsandtechnology.
Itwillneverbenecessarytoperformanupdatetoanexisting,correctlyfunctioningsystem,butduringinstallationor
serviceitisrecommendedtochecktheinstalledversiontobesureitisthenewestavailable.
Forfullupdateinstructions,seethesectiontitled,“FirmwareUpdate”intheCongurationUtilitymanual.Newrmware,
the Conguration Utility, and the Conguration Utility manual are available for download on the Support Tab of the
B-500-MTRX-230-4X4productpageatwww.SnapAV.com.
9.1. IR Source Routing
9.2. IR Front Panel IR Enable
9.4. Front Panel Power Button Active
9.3. Matrix Control from Room Enable
TheIRSourceRoutingfeatureallowsdiscretecontrolofthesourceselectedfromanyconnectedHDBaseToutputusing
anIRreceiverpluggedintotheB-500-RX-230-IR.Thissettingisonlyrelevantwhenusingin-roomIRremotestocontrol
sourcesconnectedtothematrixswitcher.WhensettoYes,thematrixwillroutecommandsfromtheHDBaseTReceiver
totheIROutputtoSourceportthatmatchesthesourceinputnumbercurrentlyselectedonthatoutput.
WhensettoNo,commandswillbesentonlyoutoftheIROutputtoSourceportthatmatchestheHDBaseTReceiver
numberfromwhichitoriginated.
ThissettingcontrolstheoperationofthefrontpanelIRreceiverbuiltintotheB-500-MTRX-230-4X4.Thisshouldbe
disabledifusingtheSYSTEMIRINporttocontrolthematrixswitcherviaIR, orifthematrix switcherismissingor
receivingextracommandsduringuse(strayIRinterferingwiththeport).
TheFrontPanelPowerButtoncanbedisabledifdesired.Disablethebuttonwhenthematrixswitcherisprogrammedto
beonatalltimesorinjobswhereturningoffthematrixfromtheswitchercancauseissueswithcontrol.
TheMatrixControlfromRoomEnableoptionallowsMatrixControlIRcommandstobesentfromtheroomasifasource
werebeingcontrolled.Turnthisoptionoffifthematrixswitcherisbeingcontrolledbyanyothermethodthanin-roomIR.
Note: To use Matrix Control from Room, it is recommended to program a universal remote control with discrete commands
for matrix control to keep in each zone, rather than using the included IR remote or commands learned from it.
Go to the Support Tab of the B-500-MTRX-230-4X4 product page at www.SnapAV.com to see and download the
available IR codes and drivers for IR remote programming.
Default Setting: Yes
Default Setting: Yes
Default Setting: Yes
Default Setting: Yes
