TECHNICAL
HDMI Compliance HDMI 3D
HDCP Compliance Yes
Video Bandwidth 6.75Gbps
HDMI over UTP Transmission
Resolution Cat5e/Cat6 Cat6a
1080i/720p24-bitcolor 200ft 230ft
FullHD1080P24-bitcolor 200ft 230ft
FullHD1080P36-bitdeepcolor 200ft 230ft
Input TMDS Signal 1.2Volts(peak-to-peak)
Input DDC Signal 5Volts(peak-to-peak,TTL)
ESD Protection
(1)Humanbodymodel—±15kV(air-gapdischarge)&±8kV(contact
discharge)(2)Corechipset—±8kV
IR Signal (Bi-directional) Carrierfrequency:20-60kHz
CONNECTIONS
HDBaseT Link 4xRJ45
HDMI 4xHDMITypeA(19-pinfemale)
IR (In) 1x3.5mmMono
All IR (Out) 1x3.5mmMono
IR Input to Room 4x3.5mmMono
IR Output to Source 4x3.5mmMono
RS232 Control Port DB9
Power Latch-Locking
MECHANICAL
Housing Metalenclosure
Dimensions (W x H x D) 17.32”x1.73”x6.38”(withoutears)
Weight 5.1lbs.
Power Supply 24VDC2.7A
Power Consumption 30w
Operation Temperature 32~104°F
Storage Temperature -4~140°F
Relative Humidity 20~90%RH(nocondensation)
CerticationsandCompliance
Product:CE,FCC
PowerSupply:CE,FCC,UL
