Binary B-500-MTRX-230-4x4 - Rear Panel Connections

B-500-MTRX-230-4x4 Installation Manual
Pg. 6
© 2013 Binary
™
6.2. Rear Panel
1. HDMI Inputs 1 through 4
 ConnectHDMIcablesfromsourcestothematrixswitchfordistribution.
2. RS-232 control port (DB9)
 AttachconnectionfromcontrolsystemorWindowsPCforserialcontroloftheB-500-MTRX-230-4X4.
3. IR Output to Source 1 through 4
3.5mmmonominiconnectionsusedtoconnectIRashersforcontrollingsources.Theseportsmaybeconguredto
routecommandsonlyfromtheIRoutputcorrespondingtotheHDBaseToutputnumber(IRzonerouting),ordirectly
tothesourceselectedforviewingonanHDBaseToutput(IRsourcerouting).(SeeCongurationUtility)
4. RJ45 HDBaseT Outputs 1 through 4
Connect568BterminatedCat5e/6HDBaseTcableroutedtoaB-500-RX-230-IRupto230feetawaytofeedHDMI
signaltodisplay.OutputsimultaneouslydisplaysthesamesourceastheHDMIoutputofthesamenumber.
5. Link LED
 ThegreenLinkLEDsindicatethestatusoftheHDBaseTconnection.Off=Nolink;On=Linkisactive.
6. HDMI Outputs 1 through 4
 ConnectHDMIcablestoroutetodisplays.OutputsimultaneouslydisplaysthesamesourceastheHDBaseToutput
ofthesamenumber.
7. IR Input to Room 1 through 4
 3.5mmmono-miniconnectionforIRpass-through.ConnectthecontrolsystemIRFlasheroutputstosendcommands
todisplaysorotherdevicesintheroom(onlywhenusingtheB-500-RX-230-IRtoextendtodisplays).
8. System All IR Out
 3.5mmmonominiport,repeatsallIRcommandsfromallconnectedHDBaseToutputs(fromIRReceiverportof
B-500-RX-230-IR).
9. System IR In
 3.5mmmonominiIRinputportformatrixcontrol.
10. Latch-Locking Power Jack
 24V2.7ADCpowersupplyportwithlockingscrewcollarforsecureconnection.
LINK LINK LINK LI NK
1 3
2 4
1 3
2 4
24V DC 2.7A
2 3 4 7 8 1061 95
