B-500-MTRX-230-4x4 Installation Manual
Pg. 26
© 2013 Binary
™
Use this chart to identify the sources and displays attached to the system, and make any notes about each part.
Whencompletingtheoutputschart,makesuretoindicatewhetheranHDMIcable,B-500-RX-230-IR,oranotherbrand
HDBaseTreceiverisbeingusedtoextendsignaltothedisplay,andindicatetheapproximatelengthofanycables.
Input
Number
Source Brand
and Model Location
Cable
Length Notes
1
2
3
4
Output
Number
Display Brand
and Model Location
HDMI or
HDBaseT
Cable
Length Notes
1
2
3
4
14. System Layout Chart
