Binary B-500-MTRX-230-4x4 - EDID Learning and Status

B-500-MTRX-230-4x4 Installation Manual
Pg. 18
© 2013 Binary
™
8.4.2. How to Set Embedded EDID for a Single Input
8.5.1. How to Learn EDID to a Single Input
8.4.3. How to Set Embedded EDID for All Inputs
Example: Input =1 Embedded EDID=4 Display Readout (Example)
1. PressDEFAULT
E-
2. PressNumberKey(1-8)toselectoneEmbeddedEDID
4A
3.PressINPUT
4A
4. PressNumberKey(1-4)toselecttheInputtowhichtheEDID
isapplied
41
5. PressENTER
(success)
(fail)
--
FF
Example: Input =1 Embedded EDID=4 Display Readout (Example)
1. PressDEFAULT
E-
2. PressALLtoselectallInputs
A-
3.PressNumberKey(1-8)toselectEmbeddedEDID
4A
4. PressENTER
(success)
(fail)
--
FF
8.5. EDID Learning
FormoreadvancedEDIDconguration,learningcanbeusedtoassignEDIDsdirectlyfromdisplaystooneormore
inputs.Thisisusefulwhenthesystemcontainsadisplaythatcannotacceptthehighestresolutionavailablefrom
sources,butallsourcesneedtobeavailabletoalldisplays.
Note: EDIDs can be learned from displays connected via the HDBaseT or the HDMI output.
When to Use Learned EDIDs
• AnolderdisplaydoesnotworkproperlywithanyoftheembeddedEDIDs.
• WhenthesourceisaPCitmaybenecessarytousealearnedEDID.
• LearningEDIDtoasingleinput
Example: Input =1 EDID Learned from Output 4 Display Readout (Example)
1. PressLEARNonceforHDMIportortwiceforHDBaseTport
L.-.
2.PressOUTPUT
1A
3.PressNumberkey(1-4)toselecttheOutputtheEDIDis
learnedfrom
14
4.PressINPUT
L-
5.PressNumberKey(1-4)toselecttheInputtowhichtheEDID
isapplied
1A
6.PressENTER
(success)
(fail)
--
FF
