BD/ED/FD (E2) Service Manual
State: 01/2002 Created: 06/2002 / Jochen Tussinger
12
To take out the fan-motor with axis, you have to
remove the rear-wall of the chamber.
Tool: Screwdriver (Phillips-Screw)
Now disconnect the connection-wires at the fan,
if possible mark them for right connection when you
put in the new fan.
To take out the fan-motor with axis, you have to
remove the three Phillips-screw at the triangle.
Now it is possible to take out the complete part.
