Appendix: Specification sensor
Choice of sensors Transmitter can be combined with different sensors of the COMBIMASS® series:
Sensor geometry: 1-pin type, 1½-pin type, 2-pin type, special geometries
Process temperature: max. 1100°C
Operating pressure: max. 100 bar
Diameter of sensor rod: 12 mm, 18 mm, 25 mm
Materials: 1.4571 (standard)
1.3981 (standard for process temperatures > 370°C)
1.4435, HC 22, special materials (optional)
Approvals: PED test certificate, modules B+F or module G (optional)
Certificates: 3.1B material certificate (optional)
Type of flow element: Insertion flow element
Inline flow element
Process connections: Compression fitting, butt weld,
screw, flange (DIN, ANSI),
retractable packing gland
Hot tapping: manually acutated with ball valve,
lead-screw actuated with ball valve,
hydraulically actuated with ball valve,
depending on the operating pressure of the medium
