COMBIMASS
®
compact
Doc. No.: 0905AE20500 48
Kapitel 3 Appendix
Select the next menu by pressing ⇓.
Display:
SUMM. RESET
Enter by pressing SET.
Display:
RESET NO
Use the ⇓- and ⇑-button to choose the desired function.
For example:
RESET YES
Accept by 1x SET and confirm the possible question to reset the counter.
The pulse:
Menu: PULS
Value: Configuration of the pulse output
Starting from the normal operation display, press SET followed by pressing the ⇓-button twice to get to
the pulse menu.
Display:
PULS
Enter the menu PULS (1x SET):
Display:
PULS CFG.
The pulse function is turned on or off with the function PULS CFG. (1x SET):
PULS -ON
By pressing the ⇓- and the ⇑-button, the desired value can be selected.
Accept by 1x SET and confirm the possible question to either turn the pulse on or off.
If the pulse is turned on, the pulse rate has to be set in the PULS RATE menu:
Enter sub menu
PULS RATE.
Display:
For example:
2[NcM]
By pressing the ⇓- and the ⇑-button, the desired value can be selected.
Accept by 1x SET and confirm the possible question to save the new pulse rate.
Important: If you recently turned on the pulse, always set the PULS RATE to a minimum of
1 Nm³.
Important: If you have a higher maximum flow than about 7,000 Nm³, you have to choose a value so it is
ensured that the device also reaches a maximum of 7,000 pulses per hour if the maximum flow is above
7,000 Nm³. (For example a maximum flow of 20,000 Nm³/h equals a pulse rate of min. 3 Nm³
[3 * 7,000=21,000].)
NOTE
