Appendix: Specification Massflow Meter
[ ] Offer
[ ] Order
[ ] Call for tenders
[ ] Specification Massflow Meter, Model COMBIMASS® compact
Fully electronic massflow meter consisting of sensor and electronics. Direct massflow measurement, independent on pressure and temperature.
Sensor without moving parts, robust, wearresisting and maintenance free. especially
suitable for low velocity and pressure. dynamics ideal for displaying ,bilancing and controling ! Span up to 1 : 100 possible with nearly constant
accurracy.
Repeatability: +/- 0,5 % of value
Supplier: BINDER GmbH, Buchbrunnenweg 18, D-89081 Ulm,
phone: +49 (731) 18998-0, fax: +49 (731) 18998-99
Series / Typ: [x] COMBIMASS® compact
Scale of delivery: ready for installation
PROCESS DATA:
Tag:
Media: Composition:
Solids:
Norm condition: [ ] 0 °C, 1,013 bar [ ]
Flow rate: Minimum: Normal: Maximum:
Unit: [ ] Nm³/h [ ] m/s [ ] kg/h
Calibrated Span: [ ] 1 : 10 [ ] 1 : 100 [ ] 1 :
Corresponding to: from to [ ] Nm³/h [ ] m/s [ ] kg/h
Pipe size: DN Inner diameter (Di): mm
Or channeldimension: Hight: Width: wall strenght: mm
Pressure: Min.: Normal: Max.: [ ] bar g [ ] mbar g
Temperature: Min.: Normal: Max.: [ ] °C
SENSOR DATA (by BINDER GmbH)
Sensormaterial: [x] Stainless steel 1.4571 [ ] Stainless steel 1.4435 [ ]
[ ] Pernifer 1.3981 (>370°C ) [ ] Hastelloy C22 (max. 370°C) [ ] Inconel (max. 370°C)
[ ] Tantal (max. 370°C)
Sensordesign: [ ] 1 PIN [ ] 1 1/2 PIN [ ] 2 PIN
Designtemperature: [ ] 130 °C [ ] 220 °C [ ] 370 °C, shot cooling neck
[ ] 580 °C, long cooling neck [ ] 800 °C, long cooling neck [ ] 1100 °C,spec.coolingneck
Sensordiameter: [ ] 18 mm [ ] 25 mm ( spec. materials )
Design: number of probes: 1 number of sensorpoints per probe: 1
End support: [] no [ ] yes ( at site )
INSTALLATION
Pipe run: [ ] Horizontal [ ] Vertical [ ]
Mounting: [ ] side [ on the top [ ]
Flow direction
(looking at the backside of the
sensor)
[ ] right to left
[ ] down
[ ] left to right
[ ] up
[]
[]
Upstream diameter m (straight pipe run)
Downstram diameter: m (straight pipe run)
Prozess connection: [ ] ¾" BSP male thread compression fitting, material: 1.4571, Viton Seal
[ ] 1 ¼" BSP male thread compression fitting, material: 1.4571, Viton Seal
[ ] Hot tapping unit with ball valve for mounting and dismantling under pressure
[ ] Hot tapping unit DVGW with ball valve for mounting and dismantling under pressure
ELECTRICAL DATA
Power supply: [ ] 18 - 36 VDC ( 230 VAC possible at site via standard power pack )
Signal output: [ ] 4-20 mA active ( isolated ), resolution 10 bit
[ ] Pulse ( isolated ), free programmable, max. 30 pulses / s )
Corresponding to: from to [ ] Nm³/h [ ] m/s [ ] kg/h
Option: [ ] 10-digit alphanumeric 1-line LED-Display in the transmitter housing for the local
indication ( actual flow or totalizing of alternating )
control panel for local operation and programming via magnetic pin
simple, logical operation
Design: [ ] Sensor and Elektronic compact, Housing stainless steel 1.4571, rotating gland
Protection class: [ ] IP 65 [ ] EEx(ed) Zone 1 [ ] EEx(ia) Zone 0 including
SPECIALS
