Kapitel 3 Appendix
Enter the sub menu CORRECTION by 1x SET.
Display:
CORR-FACT.
Exiting a menu:
To exit a menu select [ EXIT ] and confirm by pressing 1x SET. Alternatively you can wait until the device
returns to the next higher menu level by itself.
Changing a value:
1. Select an appropriate sub menu function.
2. Change the value by pressing ⇓ and ⇑ until the desired value is displayed.
3. Confirm by 1x SET.
4. Answer the question: SAVE YES/ NO with 1x⇑ YES to activate and confirm with SET.
Example:
The brightness of the display is to be changed. (Menu: DISPLAY)
Starting with the normal operation display, the following buttons have to be pressed:
Enter the menu by 1x SET.
Display:
DIMENSION
Select the sub menu DISPLAY by 5x ⇓.
Display:
DISPLAY
1x SET to enter the sub menu:
Display:
Brightness
1x SET to be able to change the intensity of brightness:
Display:
----100%----
Change the intensity by pressing ⇓ and ⇑ up to the desired value.
For example:
----30%-----
1x SET to be able to save the value:
Display:
Save NO
Switch to Save YES by pressing the ⇑-button:
Display:
Save YES
1x SET to confirm and return to the menu:
Display:
Brightness
By 1x ⇓ the function [ EXIT ] is selected.
Display:
