The menu contains the following:
■ With the Full-Scale (20mA) you can change the value that the device shows with a complete deflection
on the analog output. The value is specified in Nm³/h. It can be reduced to max. 10 % of the final ca-
libration value.
■ With the damping function the integrating time of the device can be changed. The device uses the
average of the measured values out of the time period set in the damping function. Range: 0.0 sec. to
600 sec.
■ The navigation and manipulation of the values in this menu works like already explained for the other
menus (for example 'The summation').
The correction menu:
Starting from the normal operation display, press the S-button followed by pressing the ⇓-button four
times to get to the correction menu.
Start the sub menu by pressing the S-button.
■ The Corr.-Faktor is a multiplier which multiplies the measured value. It can correct the indicated mea-
sured value, for example as a result of changes in the device or established deviations of the measured
value (gas compositions, flow profile etc.)
■ Note: The analogue 20 mA signal changes proportionally to the Corr.-Faktor and must therefore be
reprogrammed.
■ The T2-Corr.-Faktor is generally set by the manufacturer and shouldn't be changed!
-ANALOG-OUTPUT-
Full-Scale (20mA)
Damping
-------RETURN-------
DIMENSION
SUMMATION
PULS
Analog-Output
Correction
Info
-----CORRECTION-----
Corr.-Faktor
T2-Corr.-Faktor
