BINDOMATIC 301 DFS - Main Components

8 Getting to know the Bindomatic 301 DFS
Main components
Below is an illustration of the main external components of the 301 DFS. Take a few minutes
to become familiar with these components.
1. Set Collating Door
2. Manual Feeder Door
3. Left Front Door
4. Right Front Door
5. Cover Tray 1
6. Cover Tray 2
7. Document Guide
8. Output Tray
9. Attention Lamp
10.Control Panel
11. Power On/Off Switch
1
2
3
4
5
6
7
8
9
1011
