92 Biodex Medical Systems, Inc. © 2017
Figure 10.4. Squirt one-half tube of lubricant between the belt and deck.
Treadbelt Adjustment
1. Remove the 6 Phillips head screws
from the cover. Lift the cover off
the treadmill.
Figure 10.5. Treadmill Cover
