Chapter 10. Trace
The saved measurement results may be viewed using the Trace function. Data measured for 72 hours
are saved. Trace data can be reprinted or copied as images to USB
1) Trace area
① These are data for an area of 30~240bpm, which indicate the traces of fetal heart rates.
Markers or note entries are displayed at the bottom grids.
② FMD: Automatically detected fetal movements are displayed.
③ TOCO values in the range of 0~99 Units; ditto for graphs of fetal movements detected from US.
④ Scroll bar: This is used to move the time point of Traces. Time points may be moved by touching
the scroll bar or by using the cursor movement key on the operation panel.
⑤ TOCO Zeroing: This indicates that TOCO Zeroing has been done.
The figure above shows Zeroing.
⑥ Grid: This indicates the standard of the grids.
