28
Table 3-8 indicates the factory settings and user selectable
communication parameters by using RS-232 interface (standard) and
GPIB interface (option).
Table 3-8. Communication Parameters
Menu Item Factory Setting Selectable Parameters
Remote RS-232 RS-232 or GPIB
Baud Rate 9600
9600, 4800, 2400, 1200, 600,
and 300
Parity None None, Odd or Even
Data Bit 8 7 or 8
Stop Bit 1 1 or 2
ECHO OFF ON or OFF
Printer-Only OFF ON or OFF
Address 8 0 to 30
Talk OFF ON or OFF
Beeper
(1)
ON ON or OFF
(1)
The Beeper mode is not a communication related parameter but to simplify
the meter operation.
3-11 Selecting Local Operation Mode
to return the operation control priority from remote mode (computer
controlled) to local mode (user controlled).
