86
Models
8620
8622
8624
8625
Transient Mode (CC mode)
T1 & T2
1
20 µs – 3600 s/Resolution: 10 µs
Accuracy
5 µs + 100 ppm
Slew Rate
2
Low
Rate
0.001-0.25 A/µs
0.0001-0.1 A/µs
0.001-0.25 A/µs
0.001-0.25 A/µs
High
Rate
0.01-2.5 A/µs
0.01-1 A/µs
0.01-2.5 A/µs
0.01-2.5 A/µs
Accuracy
within 40% of programmed value
Measurement
Readback Voltage
Range
Low
0 – 18 V
0 – 50 V
0 – 18 V
0 – 18 V
High
0 – 120 V
0 – 500 V
0 – 120 V
0 – 120 V
Resolution
Low
1 mV
High
10 mV
Accuracy
±(0.025%+0.025%FS)
Readback Current
Range
Low
0 – 48 A
0 – 10 A
0 – 60 A
0 – 72 A
High
0 – 480 A
0 – 100 A
0 – 600 A
0 – 720 A
Resolution
Low
1 mA
High
10 mA
Accuracy
±(0.05%+0.1%FS)
±(0.05%+0.05%FS)
±(0.05%+0.1%FS)
±(0.05%+0.1%FS)
Readback Power
Range
3000 W
2500 W
4500 W
6000 W
Resolution
100 mW
Accuracy
±(0.2%+0.2%FS)
Protection Range (typical)
OPP
3050 W
2550 W
4550 W
6050 W
OCP
Low
26.4 A
11 A
66 A
79.2 A
High
264 A
110 A
660 A
792 A
OVP
130 V
530 V
130 V
130 V
OTP
85℃
General (typical)
Short Circuit
Current
(CC)
Low
52.8 A
11 A
66 A
79.2 A
High
528 A
110 A
660 A
792 A
Voltage
0 V
Resistance
5 mΩ
30 mΩ
3 mΩ
2.5 mΩ
Input Terminal
Impedance
300 kΩ
1 MΩ
300 kΩ
300 kΩ
Notes:
1) Fast pulse trains with large transitions may not be achievable.
