20
3.2 Configure Operation Modes (CC/CV/CR/CW)
The electronic load can work in the following modes:
1) Constant current (CC) operation mode
2) Constant voltage (CV) operation mode
3) Constant resistance (CR) operation mode
4) Constant power (CW) operation mode
Constant Current (CC) Mode
In this mode, the electronic load will sink a current in accordance with the programmed value
regardless of the input voltage.
Configure CC Parameters
There are several parameters that should be setup prior to operating in CC mode. Press
so that it lights up, then press ( ) and to access Setup for CC mode.
The setup menu will be shown:
