BK Precision 8601 User Manual

18
3 Front Panel Operation
3.1 Menu Options
Most settings and parameters can be configured from the built-in menu systems of the
instrument. There are two main menus: System and Config.
System Menu
To access the system menu, press ( ) then ( ).
The system menu will have the following options:
Initialize
Reset load settings to factory default values.
Power-On
Configure power-on state.
Buzzer
Enable/Disable key sound.
Knob
Controls update method when using knob to control load.
Trigger
Configure Trigger.
Memory
Select memory location for save/recall instrument settings.
Displ (Display)
Enable/Disable load ON timer.
Communication
Select communication interface.
Protocol
Select standard SCPI or extended set of protocols for remote
communication.
Config Menu
To access the system menu, press ( ) then ( ).
The system menu will have the following options:
Von
Configures Von function
Protect
Configures protection parameters and limits
Measure
Configures measurement parameters
CR_LED
Enables/Disables CR LED function
Remote-Sense
Enables/Disables remote sense
Ext-Program
Enables/Disables external analog control
