60
6. To disable list operation, first press to disable the input and then press and
(or press ). Select Off and press to confirm. The Trig annunciator will
disappear when list operation is disabled.
3.8 Battery Test Function
The load has a built-in battery test function that uses CC mode and calculates the battery
capacity using a fixed current load. The test’s stop conditions can be specified by the following:
Stop Voltage: Set a cut-off voltage level. When this level is reached, the test will end. Valid
range: 0 V – max. rated voltage.
Stop Capacity: Sets a capacity level. When the calculated capacity reaches this level, the test
will end. Valid range: 0 Ah – 999.99 Ah
Stop Timer: Sets a timer. When the specified time is reached, the test will end. Valid range: 0
s – 99999 s.
During operation, the load will sink current at the specified level while measuring and updating
the capacity value in amp-hours (Ah) and tracking the time period of the test. When any one of
the three stop conditions above is met, the test will end, and the display will show the
measured capacity and time results.
To setup and run the battery test function, follow the steps below:
1. Disable the input of the load and connect it to the battery to be tested.
2. Press and use the numeric keypad or rotary knob to enter a current sink value
for the test. Press .
3. Press ( ) and ( ) to configure and enable the battery test function.
4. The load will prompt to enter all three test stop conditions, starting with Stop Voltage
value. Use the numeric keypad or rotary knob to enter a voltage level. Then press
to continue.
5. The load will prompt to enter the Stop Capacity. Use the numeric keypad or rotary
knob to enter a capacity value in Ah. Then press to continue.
