33
3. Use the current adjust knob or the numeric keypad to enter the memory location in
which to store current instrument settings. Select between 0 – 100. Press to
save to the selection location.
NOTE:
The “0” memory location is reserved for storing instrument settings last configured
before power-off and is used only for power-on state configuration only.
Recall Settings
1. First, consider the memory locations you want to recall from. As they are grouped
together, select the appropriate storage group from the SYSTEM menu first by following
the instructions in previous section.
2. Once selected, press and (or press ) and it will light up to indicate
the instrument is in Recall mode.
3. Use the keypad numbers to recall the settings from the corresponding memory location
referenced by the storage group selected in Step 1.
4. Once entered, the saved settings at the location will be immediately recalled.
Note: When in Recall mode, users can recall settings from different locations
without having to press additional keys each time. For example, you can
press 1 to recall settings in location one, and then press 5 to recall settings
in location 5 on the fly.
5. To exit Recall mode, press .
