69
PRG01 from this display indicates which program has been loaded to run. Depending on
which program is recalled, it will show PRG01-PRG10.
STOP indicates the program is not running.
4. Now, press ( ) once to start running the program. The display will change to:
-01 next to PRG01 indicates the current running sequence number within the selected
program number.
on indicates the input state is enabled for the selected sequence. If On Time is not set
to 0.0S for the sequence, it will show on. This indicator can also show off to indicate the
input state is disabled. If short is selected for the sequence, it will display short.
pass indicates at the current sequence has passed the test. If a failure occurs, it will
indicate fail.
5. If pause is activated for a selected sequence while running the program, the display will
show:
