76
6. Follow the same steps for Step Power and End Power. Press
after each settings to continue.
7. Enter a value for OPP Voltage and press to continue.
8. Enter a value for Max Trip Power, and then Min Trip Power. Press
after each settings to continue.
9. The load will prompt to Save OPP File. Select a number between 1 and
5. Then press to save all settings to the selected location.
Note: At any time when configuring any parameters for the test, you can press the
( ) key to select the previous parameter to edit.
To recall the settings:
1. Press ( ) and to enter the OPP Test menu.
Select Recall and press .
2. Use the keypad or knob to select the saved location number and
press . All settings will be recalled when selecting Edit
from the OPP Test menu.
To run the OPP test:
1. Recall the settings from memory by following the steps above.
2. From the OPP Test menu, select Run and press . The display will show the
following:
